Xmost M12 Y-coded male front mount PCB connector provides a combined Ethernet and power connection for industrial equipment. Its hybrid interface mates with a compatible Y-coded female cable connector, bringing separate signal and power circuits through one panel-mounted connection.
Straight rear contacts support PCB insertion and dip soldering. The front fastened construction is available with PG9 or M16 × 1.5 mounting threads for integration into the equipment enclosure.
Select Y3 for four signal contacts plus two power contacts, or Y4 for four signal contacts plus four power contacts. Y3 power contacts are rated at 12 A, while Y4 power contacts are rated at 6 A. Signal contacts are rated at 0.5 A in both configurations.
Key Features
- Ethernet and power in one interface: Combines separate signal and power contacts in one M12 hybrid connector.
- Y3 or Y4 configurations: Choose six or eight total contacts.
- Separate current ratings: Y3 power contacts: 12 A; Y4 power contacts: 6 A; signal contacts: 0.5 A.
- Front fastened mounting: PG9 or M16 × 1.5 panel thread options.
- PCB dip-solder termination: Straight rear contacts connect to the internal circuit board.
- Shielded construction: Provides a shielded interface for the equipment’s hybrid cable connection.
Product Dimensions
[Insert the male front mount outline drawing and corresponding panel cut-out drawing from page 24.]
Illustrated PG9 Front Mount Version — Dimensions in mm
| Item | Drawing Value |
|---|---|
| Mating thread | M12 × 1.0 |
| Panel mounting thread shown | PG9 |
| Upper axial section | 9 |
| Middle axial section | 9 |
| Lower axial section | 2.5 |
| Upper wrench size | SW13.4 |
| Mounting nut wrench size | SW17.9 |
| Rear contact section | 6 |
| Contact tip section | 3 |
The page uses a general outline with contact-diameter notes for other pin counts. Confirm the Y3 or Y4 contact diameters against the selected product drawing.
Needle Arrangement (Front View)
[Insert the Y3 and Y4 male needle arrangement diagrams from page 24.]
| Configuration | Signal Contacts | Power Contacts | Total Contacts |
|---|---|---|---|
| Y3 | 4 | 2 | 6 |
| Y4 | 4 | 4 | 8 |
The diagrams show the male mating-face view. Match the complete arrangement to the female cable connector and use the equipment schematic for Ethernet signal assignments and power polarity.
Product Specifications
| Parameter | Specification |
|---|---|
| Product type | M12 Y-coded male front mount PCB hybrid connector |
| Mounting | Front fastened |
| Function | Ethernet signal and power |
| PCB contact style | Straight |
| Termination | PCB dip soldering |
| Standard listed | IEC 61076-2-113 |
| Rated voltage | 50 V AC / 60 V DC |
| Shielding | Shielded |
| Mating thread | M12 × 1.0 |
| Panel mounting threads | PG9 / M16 × 1.5 |
| Insulation resistance | ≥100 MΩ |
| Contact resistance | ≤5 mΩ |
| Recommended coupling torque | 0.4 N·m |
| Maximum coupling torque | 0.8 N·m |
| Temperature range, flexible use | −25°C to +80°C |
| Temperature range, static use | −40°C to +80°C |
| Protection ratings listed | IP67 / IP68 / IP69K |
| Pollution degree | 3 |
| Insulator materials listed | PA66+GF / TPU+GF |
lectrical Ratings by Configuration
| Configuration | Contact Arrangement | Power-Contact Current | Signal-Contact Current |
|---|---|---|---|
| Y3 | 4 signal + 2 power | 12 A | 0.5 A |
| Y4 | 4 signal + 4 power | 6 A | 0.5 A |
Applications
- Ethernet-enabled automation modules: Connects network signals and power through one panel interface.
- Distributed industrial devices: Links a hybrid cable assembly to internal signal and power circuits.
- Modular machine electronics: Provides a detachable connection for equipment combining communication and power.
- Equipment with limited panel space: Consolidates the specified circuits into one M12 connector.
Selection and Ordering
| Configuration | PG9 Mounting | M16 × 1.5 Mounting |
|---|---|---|
| Y3 — 4 signal + 2 power | 1M1207YM06MP9PS | 1M1207YM06M16PS |
| Y4 — 4 signal + 4 power | 1M1207YM08MP9PS | 1M1207YM08M16PS |
Example enquiry: M12 Y-coded male front mount PCB hybrid connector, Y3, shielded, PG9 mounting, part number 1M1207YM06MP9PS.
